Experimental data

Experimentally produced object 2.7

EPO2.7

ID3

LocationNorway

Approximate number of models23

Approximate size132 GB

Experimentally produced objects for the purpose of the TEMPA 3D project. Experiments were held in January and November 2024, and included engraving of soapstone from Rennesøy and Målslev and sandstone from Kamyana Mohyla. Experimentally produced objects were specifically designed to look at the technological traces of the surface modification processes via image-based 3D modeling.

Dataset includes 23 models of the experimentally produced objects. Among other this includes flint and quartz marks on soapstone, sandstone, bone, and antler as well as experimental replicas of Kamyana Mohyla churinga and soapstone line sinkers. For most engravings the modification time was recorded along with the production tool. The accuracy of the models in the dataset are around 0.1 mm, the resolution — around 0.03 mm.

Metadata

Material

Bone

Material of the surface modification tool

Flint

Quartz

Description of the object

Long and dry fragment of the deer bone. Sawed with different types of material for recorded time — 30s, 60s, 90s, and 120s. Engraved wil flint and quartz tools

Description of the tool

Flint blade; flint burin; quatrz blade; bifacial flint point

Material source

Deer bone

Current location

Arkeologisk Museum, Universitetet I Stavanger

Date of the experiment

08.11.2024

Experimental session ID

Experimental object ID

Actor name

Simon Radchenko

Type of surface modification 1

Sawing

Type of surface modification 2

Incising

Type of surface modification 3

—

Paradata

Data acquisition technique

Image-based 3D modeling

Data acquisition date

21/11/2024

Data acquisition equipment

Canon EOS D5s R, Zeiss Milvus, f/1.4, 50mm, extension ring 12mm, polarizing filter

Focal length

Aperture

1/32

ISO

200

Exposure

1 s

Image processing software

Adobe Photoshop

3D model creation software

Agisoft Metashape v. 1.8.1.

Capturing strategy

66 digital images in RAW format. 5 linear loops with the view from the top under different angles (from 55 to 90 degrees). SfM photogrammetry, static camera within scenes, an artifact on the turntable, black background; scaled from calibrated metric scale bars. Remote shutter release.

Format of supplementary files

*.mtl

File format / 3D model

*.obj

Number of facets

13,215,422

Length of triangle side

0.04 mm

Referencing accuracy

0.056 mm

Measuring accuracy

0.09 mm
